Titan tayoq uchlari

mahsulot: titanium stend uchlari
Standart: ASTM B363, ANSI B16.9
Hajmi: 1/2 "dan 24" gacha
Materiallar darajasi: Gr1, Gr2, Gr7, Gr12
Ulanish turi: bw
MQQ: 1 dona

So'rov yuborish

Hozir chat

Mahsulotni tanishtirish

WTD sanoat bozori uchun 2-darajali titanium novdalar va boshqa titan quvurlari armaturalarining katta tanloviga ega.

A tipidagi MSS Short, ANSI Long va Type B MSS Short hammasi mavjud. O'lchovli toleranslar ASME B16.9 ga mos keladi.

Titan quvurlari armatura devor qalinligi ASME B36.19M standart jadvaliga javob beradi, masalan, 10S va 40S devor quvurlari. yuzalar ASME B16.5 bo'yicha qayta ishlangan qoplamali titanium novdalar uchun maxsus buyurtma asosida mavjud. Otish yoki tuzlashdan foydalangan holda oddiy sirt (kichik o'lchamdagi barcha portlatish ishlatiladi, katta o'lchamdagi tuzlash yuzasi ishlatiladi)

ASME B16.9 ga muvofiq titaniumli payvandlash armaturalarini doimiy ravishda yorliqlash uchun elektrokimyoviy ishlov berish yoki lazer belgilaridan foydalaniladi.

Mahsulot tavsifi

Mahsulot nomi	Titan tirgak uchi
Brend	WTD
Material	Gr1, GR2, GR3, GR7, GR12
Standart	ASTM B363, ANSI B16.9
Hajmi	DN 15 dan DN 600 gacha, 1/2" dan 24" gacha
Turi	Uzoq (ANSI) va qisqa (MSS)
ulanish turi	payvandlangan (BW)
Yuzaki	portlatish yoki tuzlash yuzasi
lazer markalash	Ha
MOQ	1 dona

Qopqoq uchining o'lchamlari

TITANIUM STUB ENDS

						Sch10			Sch40
NOM. Quvur o'lchami	DIA TAShQIRI.	LAP DIA.	RADIUSNI TYING	UZUNLIK (L) MSS ANSI		ICHKI DIA.	DEVOR QALINLIGI	LAP QALINLIGI	ICHKI DIA.	DEVOR QALINLIGI	LAP QALINLIGI
Dyuym	(OD)	(G)	(R)	QISQA	UZOQ	(ID)	(T)	(t)	(ID)	(T)	(t)
1/2	0.840	1-3/8	1/8	2	3	0.674	0.083	0.083	0.622	0.109	0.109
3/4	1.050	1-11/16	1/8	2	3	0.884	0.109	0.109	0.824	0.113	0.113
1	1.315	2	1/8	2	4	1.097	0.109	0.109	1.049	0.133	0.133
1-1/4	1.660	2-1/2	3/16	2	4	1.442	0.109	0.109	1.380	0.140	0.140
1-1/2	1.900	2-7/8	1/4	2	4	1.682	0.109	0.109	1.610	0.145	0.145
2	2.375	3-5/8	5/16	2-1/2	6	2.157	0.109	0.109	2.067	0.154	0.154
2-1/2	2.875	4-1/8	5/16	2-1/2	6	2.635	0.120	0.120	2.469	0.203	0.203
3	3.500	5	3/8	2-1/2	6	3.260	0.120	0.120	3.068	0.216	0.216
3-1/2	4.000	5-1/2	3/8	3	6	3.760	0.120	0.120	3.548	0.226	0.226
4	4.500	6-3/16	7/16	3	6	4.260	0.120	0.120	4.026	0.237	0.237
5	5.563	7-5/16	7/16	3	8	5.295	0.134	0.134	5.047	0.258	0.258
6	6.625	8-1/2	1/2	3-1/2	8	6.357	0.134	0.134	6.065	0.280	0.280
8	8.625	10-5/8	1/2	4	8	8.329	0.148	0.148	7.981	0.322	0.322
10	10.750	12-3/4	1/2	5	10	10.420	0.165	0.165	10.020	0.365	0.365
12	12.750	15	1/2	6	10	12.390	0.180	0.180	12.000	0.375	0.375
14	14.000	16-1/4	1/2	6	12	13.624	0.188	0.188	13.250	0.375	0.375
16	16.000	18-1/2	1/2	6	12	15.624	0.188	0.188	15.250	0.375	0.375
18	18.000	21	1/2	6	12	17.624	0.188	0.188	17.250	0.375	0.375
20	20.000	23	1/2	6	12	19.564	0.218	0.218	19.250	0.375	0.375
24	24.000	27-1/4	1/2	6	12	23.500	0.375	0.375	23.250	0.375	0.375

Grade 2 titanium long stud end

Titanium stub end ASME B16.9

GR2 titanium stub end

Gr12 titanium stub end

TSS

1) Nima uchun WTD kompaniyasini tanlaysiz?

Boy tajriba, mukammal uskunalar, etuk texnologiya. 100% o'lchovli tekshiruv, ilg'or sirtni tozalash texnologiyasi, bepul lazer belgilari, qisqa etkazib berish muddati, o'z vaqtida sotishdan keyingi xizmat

2) Qanday buyurtma berish kerak?

"Material + standart + spetsifikatsiya + miqdor + maxsus talablar" deb yozing, biz narxni talablarga muvofiq hisoblab chiqamiz va kotirovkaga elektron pochta orqali o'z vaqtida javob beramiz.

3) MOQ

1 dona

4) Buyurtmani etkazib berish uchun qancha vaqt kerak?

Oddiy 15 kun, biz mijozning talabiga binoan etkazib berish muddatini kotirovkaga kiritamiz va shartnomaga qat'iy rioya qilamiz
